1530-89-8

4-吗琳甲腈(1530-89-8)Raman光谱

产品名称:4-吗琳甲腈

CAS:1530-89-8

分子式:C5H8N2O

分子量: 112.13

InChI:InChI=1S/C5H8N2O/c6-5-7-1-3-8-4-2-7/h1-4H2

InChIKey: BOQOXLAQTDFJKU-UHFFFAOYSA-N

Smiles:N1(C#N)CCOCC1

  • 图谱
    Mass

    MS-NW-8330
    4-morpholinecarbonitrile
    C5H8N2O             (Mass of molecular ion:    112)


       Source Temperature: 250 °C
       Sample Temperature: 130 °C
       Reservoir, 75 eV


          15.0       5.0
          26.0       3.2
          27.0       9.1
          28.0      42.0
          29.0       7.5
          30.0       2.8
          31.0       2.0
          40.0       2.4
          41.0       5.2
          42.0     100.0
          43.0       5.7
          44.0       2.9
          53.0       7.6
          54.0      21.5
          55.0      47.6
          56.0       4.4
          57.0       8.5
          58.0       1.2
          67.0       4.7
          72.0       1.2
          81.0       2.1
          82.0       3.8
         111.0       2.3
         112.0      40.7
         113.0       2.8


400 MHz in CDCl3

  • 图谱

    1H NMR 399.65 MHz
    C5 H8 N2 O 0.05 ml : 0.5 ml CDCl3
    4-morpholinecarbonitrile
    ChemicalStructure
        Assign.     Shift(ppm)
    A 3.733 B 3.247

         Hz     ppm     Int.


       1510.25   3.779     26
       1505.37   3.767     45
       1497.19   3.747    942
       1492.31   3.735    890
       1490.48   3.730    508
       1487.43   3.722    933
       1315.55   3.292     25
       1310.67   3.280     43
       1302.49   3.260   1000
       1299.07   3.251    540
       1297.49   3.247    918
       1296.02   3.243    554
       1292.60   3.235    882
       1284.67   3.215     33


in CDCl3

  • 图谱

liquid film

  • 图谱

4880 A,200 M,liquid

  • 图谱

×
